Assa Abloy Norton Wave to Open 704 User Manual

Copyright © 2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9370-0002-020 Rev 2 07/20
2
Model 704 Wave to Open Switch
Power
+
N/C
C
N/O
Power -
Wiring:
For proper wire connection, loosen
screws fully and ensure silver contact
is completely down. Insert wires and
tighten screws to secure wires.
1 Sec 5 Sec 10 Sec 15 Sec 20 Sec 25 Sec 30 Sec 35 Sec
LED Setting:
Time Delay Setting:
Jumper in place: LED is
Red and ashes Green
when relay is active.
No Jumper: LED is
Green and ashes Red
when relay is active.
31 "-/4
( mm)83
13 "-/4
( mm)44.5
15/16"
(24.2mm)
5/8"
(16mm)
1-3/8"
( mm)34.9
4-1/2"
(115mm)
1-3/ "4
( mm)44.5
Ø 78/"
( mm)22
Ø 316/"
( mm)5
( places)6
3- 11/16"
(94mm)
13 16/"
( mm)20
Wave to Open Switch Conduit Housing
