Assa Abloy Yale 6170 User Manual

6000 Series Grade 1 Exit Devices
10
6170(F) LBR Surface Vertical Rod
(Less Bottom Rod)
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and
Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
Item Part No. Description
34
81-9500-1562-000 SVR Pack
Consists of the following:
60-7110-1005-048 Top Mtg. Plate
60-7010-1067-048 Top Rod Connector
99-9999-4308-999 Rod Connecting Pin (2)
60-7000-1150-999 Drill Jig
81-9500-1613-000
Latch Mounting Screw
Pack
81-9500-1576-000 726 Top Strike Packet
36 60-7010-X052-FIN Top Rod
39
81-9500-1514-FIN Rod Guide Packet
Consists of the following:
60-7010-9050-999 Guide, Rod (1)
60-7010-X051-FIN Cover, Rod Guide (1)
81-3110-0412-058
Screw, #8 x 1/2 (2)
RPHMS (4)
81-3115-0308-FIN Screw, Rod Guide Cover
81-0011-0404-FIN
Screw, #8-32 x 1/4 (2)
FPHMS (4)
55 60-7110-0002-999
Popper Packet
(6170F Only)
Item Part No. Description
1
Latch Assembly
60-6010-0360-048 LH
60-6010-0365-048 RH
6170, 6170F
2
Cover
60-6000-X014-FIN 6170
Not Available
6170F
3 03-0080-5047-FIN
Sex Nut Pack (4)
(Fire Rated Only)
4 60-1510-0281-FIN
Rod Extension Assy., 24"
(-10 Device Only)
5 60-1510-0278-FIN
Rod Extension Assy., 12"
(-10 Device Only)
23 81-9500-1549-FIN
Screw Packet, Cover
#8-32 x 5/16”
UFPHMS (5)
32 60-7010-X040-FIN Cover, Top & Latch
33 60-7010-0050-999 Top Latch, 6170(F)
