Introduction
INSTALLATION NOTES
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and
Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
1. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Yale
Locks & Hardware makes no representations or warranties concerning what such impact may be in any specific situation.
When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire rated opening, please
consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable
codes and ratings.
2. Refer to the templates and installation instructions for complete door preparation and installation requirements.
3. Machine screws are provided for steel reinforced doors, threaded-to-the-head AB Type screws are provided for wood door
applications. In addition, sex nuts and bolts are provided for fire rated devices and are optional for non-rated devices. It is
recommended that sex nuts and bolts be used for all exit device applications. This will improve the performance and extend
the life of the product.
To order parts, provide the appropriate quantity, part number, finish, hand (when required) and description as directed and
illustrated below.
For example, use the following configuration to order:
A) ten escutcheon assemblies in satin chrome
B) one surface vertical rod latch cover in bright brass
For assistance, contact your authorized Yale distributor, sales agency or visit our website at www.yalelocks.com.
1 . New May 1, 2010
Finish available with MicroShield
®
antimicrobial coating, additional finishes
by special application. Consult factory for
availability.
Quantity Part Number Finish Hand Description
A 10 60-7000-0612-FIN 630 — Escutcheon Assemblies
B 1 60-7010-X040-FIN 605 — Top Latch Cover
ANSI/BHMA Code Finish Description
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
613E Dark Oxidized Satin Bronze, Oil Rubbed
1
629 Bright Stainless Steel
630
Satin Stainless Steel
HOW TO ORDER PARTS
FINISHES
