Assa Abloy YRD136 - Installing Latch & Strike Plate

P/N YRD136-MNL-0008 Rev C
3
x4
1
Installing Latch & Strike Plate
Rotate
2-3/8" position
2-3/4" position
O
optional
Bolt must be in retracted
(unlocked) position. UP
arrow must be facing
upwards.
!
default
3
2- /
8
3
2- /
8
3
2- /
4
