19
:: Step 40
:: Step 41
Install 4
x4
x3
x2
6332
Body Clip
31532
3x8mm
BHCS
91738
M4 Black
Nut Serrated
Aluminum
25862
SC Body,
Yellow / Black
x3
91477
Nuts, M3,
Black
