Associated Electrics RC10 Classic - Nose Plate; Steering Build

:: Nose Plate / Steering Build - Bag A-AA - Step 2
:: Front Suspension Build - Bag B - Step 1
4
:: Nose Plate / Steering Build - Bag A-AA - Step 1
6281
8-32 x 7/8
aluminum
FHPS
6280
8-32 x 1/2
aluminum
FHPS
6310
RC10 front
nose plate
6931
8-32 x 1/4
FHPS
6331
RC10 body
mounts
(white)
6300
RC10
chassis
3323
#8 aluminum
washer (thick)
x2
x2
#1596
thread lock
3323
#8 aluminum
washer (thick)
6282
8-32 nut
(white)
6255
RC10
steering
assembly
6255
RC10
steering
assembly
6295
4-40 nut
x2
x2
6271
Ballstud
.20 (silver)
6271
Ballstud
.20 (silver)
6213
RC10 front
caster blocks,
15 degrees
(Left & Right)
x4
Build left and
right sides!
LEFT
LEFT
Build left and
right sides!
Tighten 8-32 nuts
until snug &
bellcrank
rotates freely!
!
LEFT
Build left and
right sides!
6299
E-clip
(small)
6216
RC10 steering
blocks
(Left & Right)
6271
Ballstud
.20 (silver)
6219
RC10 front
stub axles
Press stub axles
into steering blocks.
Use a hard surface
to push down on!
!
#1596
thread lock
