Associated Electrics RC10B6.2D KIT - Bag 2 - Step 8; Bag 3 - Step 1; Bag 3 - Step 2

:: :: Bag 3 - Step 2Bag 3 - Step 2
:: :: Bag 3 - Step 1Bag 3 - Step 1
8
:: :: Bag 2 -Bag 2 - Step 8Step 8
Build 2 (1 left, 1 right)
x2x2
31531
M3 x 6mm
BHCS
91560
5 x 10 x 4
Bearing
91682
Front Axle
91776
Steering
Block
(4mm)
#1596
thread lock
25188
M3 x 20mm
BHCS
91815
Shock
Bushing,
10mm
91768
Front Shock
Tower,
Gull-Wing
91771
Front Shock
Tower Cover,
Gull-Wing
x2x2
x2x2
Build 2 (1 left, 1 right)
91049
Heavy-duty
Ballstud,
10mm
25215
M3 Locknut,
black
91776
Caster
Block Insert
(+5°)
There are three caster
block inserts included
(0°, +/- 2.5 °, +/- 5 °).
+5 ° is the standard
insert used.
Tab up = positive caster
Tab down = negative caster
There are two sets of steering
blocks included with your kit, a 3mm
and a 4mm. The 4mm steering
blocks are used for the kit setup.
Use the outer most hole on
the shock tower for kit setup
!
!
!
!
91776
Caster
Block
You can install an
optional #31520 screw
to use as a steering
stop setting.
You can install an
optional #4670 set
screw to better hold
the caster block inserts
and hinge pin.
Total
Caster
25° 25° 30° 20°2 7. 5 ° 22.5°
0 2.5 up 5 up2.5 down 5 down
30° 30° 35° 25°32.5° 2 7. 5 °
Bulkhead
Orientation
Caster Block Insert
Bearing
Bearing
There are two sets of steering
There are two sets of steering
blocks included with your kit, a 3mm
blocks included with your kit, a 3mm
and a 4mm. The 4mm steering
and a 4mm. The 4mm steering
4L
25215
M3 Locknut,
black
91680
Steering
Block Arm
+1
91047
Heavy-duty
Ballstud,
6mm
optional #31520 screw
31532
M3 x 8mm
BHCS
x2x2
25202
M3 x 10mm
FHCS
89208
M3 x 14mm
FHCS
91865
Wing Mount,
Front
x2x2
x2x2
#91865 - Front Wing Mount is used as a tuning option to
increase front end stabillity by adding a front wing (included).
If you do not use #91865, use #25202
M3x10mm FHCS instead of #89208 M3x14mm FHCS.
