Associated Electrics RC10B6.2D KIT - Bag 3 - Step 3; Bag 4 - Step 1; Bag 4 - Step 2

:: :: Bag 4 - Step 2Bag 4 - Step 2
:: :: Bag Bag 4 - Step 14 - Step 1
9
:: :: Bag 3 - Step 3
Build 2 (1 left, 1 right) Build 2 (1 left, 1 right)
#91670 - Hinge Pin will be
tight in the caster blocks,
but should rotate freely
in the front arms.
!
91772
Aluminum
Arm Mount,
C
92014
Arm Mount
Inserts
(center)
x2x2
31541
M3 x 6mm
FHCS
x2x2
See next step for
pill chart tips
!
See next step for
pill chart tips
91685
Rear
Bumper
91688
Aluminum
Arm Mount, D
91670
Rear Hinge Pin
(Inner 3.5x48mm)
91853
B6.2 Rear
Arms, 73mm
92014
Arm Mount
Inserts
(center)
91855
Rear Arm
Sapcer
x2x2
x2x2
Anti-SquatToe-In
3°
Kit Setup
1°
Kit Setup
The (#91772) C and (#91688) D aluminum arm
mounts allow for a large amount of setup
combinations when using the (#92014) 0.5°
and 1° arm mount inserts.
For a complete list of pill setup combinations, please
visit our website by using the link or QR code below.
https://www.teamassociated.com/pdf/cars_and_
trucks/RC10B6/B6_B6D_Pill-Chart.pdf
!
D Plate
Center
C Plate
Center
31510
M2 x 4mm
BHCS
91776
Caster Block
Spacer
91670
Front Hinge Pin
(Outer, 3x226mm)
!
x2x2
25187
M3 x 14mm
BHCS
91676
Caster Hat
Bushing
Top: 1mm
Bottom: 2mm
x2x2
