:: Center Bulkhead Assembly (cont.) - Bag I & II
:: Center Bulkhead Assembly (cont.) - Bag I & II
x2
x2
Install CVA bones
into center diff
outdrives!
!
89217
4x14mm
fhcs
89214
4x12mm
fhcs
89510
Motor pad
89502
RC8e
center diff
riser
Note: trim motor
pad to fit chassis.
!
