Associated Electrics RC8B4.1e Team Kit - Rear End Assembly - Steps 7-9; Chassis Bracing and Body Mounts; Rear Body Post and Wing Setup

18
:: :: Rear End Build - Bag 7.1, 7.2, 7.3 - Step 9
:: :: Rear End Build - Bag 7.1, 7.2, 7.3 - Step 8Rear End Build - Bag 7.1, 7.2, 7.3 - Step 8
:: :: Rear End Build - Bag 7.1, 7.2, 7.3 - Step 7Rear End Build - Bag 7.1, 7.2, 7.3 - Step 7
81552
Wing Mount
89208
3x14mm
FHCS
81552
Wing Angle
Shim, -2
81553
Wing
Buttons
81553
Wing,
Black
25215
M3
Locknut
x2x2
x2x2
x2x2
x2x2
25189
3x22mm
BHCS
25612
M3
Locknut
W/Flange
81525
Chassis
Brace
Mount
81525
Chassis
Brace,
Rear
89214
4x12mm
FHCS
x2x2
CHOOSE ONE
Fin adds straight -line
stabilization.
Button adds agility
in corners.
Racer’s Tip:
Tune the
rear end for
more flex
with#81562 ball
end insert here
31532
3x8mm
BHCS
81525
Chassis
Brace
Insert
x2x2
81525
Rear Chassis
Brace Insert
x2x2
Buttons
Fin adds straight -line
Kit Setup:
89227
M3x28mm
SHCS
81508
Shock
Bushing
x2x2
x2x2
#1596
thread lock
41090
M3x10mm
LP SHCS
81524
Body Post
Mount, Rear
81558
Body Post
Grommet
81524
Body Post,
Rear
81634
B4.1 Rear
Shock Tower,
Aluminum,
36.5
89208
M3x14mm
FHCS
!
Mount, Rear
1
4
2
5
3
6
2
1
3
4
5
25215
M3
Locknut
81552
Wing
Mount
Adapter
x4x4
x2x2
89214
M4x12mm
FHCS
89454
M3x12mm
SHCS
x4x4
x4x4
Refer to previous
step (8) for wing
height position
!
