Associated Electrics RC8B4.1e Team Kit - Rear Hub Assembly - Steps 1-3; Rear Hub Construction; Rear Shock and Hub Mounting

19
:: :: Rear Hubs Build Rear Hubs Build - Bag 8.1, 8.2 - Step 3
:: :: Rear Hubs Build Rear Hubs Build - Bag 8.1, 8.2 - Bag 8.1, 8.2 - Step 2- Step 2
:: :: Rear Hubs Build Rear Hubs Build - Bag 8.1, 8.2 - Step 1
x2x2
Build two!
Install left and right side!
91564
8x16x5mm
Bearing
x2x2
25612
M3 Locknut
w/Flange
81642
B4.1 Rear
Hub Shim,
1mm
81076
Hub Hinge
Pin
#1596
thread lock
25612
M3 Locknut
w/Flange
25192
M3x20mm
SHCS
25211
M3x10mm
BHCS
89216
M4
Locknut
81264
M4x20mm
FHCS
89217
M4x14mm
FHCS
89214
M4x12mm
FHCS
x2x2
x2x2
x2x2
x2x2
25612
M3 Locknut
W/ Flange
81509
Shock
Pin
81257
M3x6mm
Set Screw
Kit Setup:
Mount the rear shock in the
outside hole on the rear arm.
ABC
Kit Setup:
Tuning Tip:
Remove screw A for “soft/
short” flex configuration.
A B
#1596
thread lock
89221
5x4mm
Set Screw
81081
Wheel Hex,
+0mm Wide
89096
Wheel
Hex Pin
25215
3x6mm
Set Screw
x2x2
Tighten set
screw before
camber link
installation.
!
Racer’s Tip:
Use a 2mm drill to punch thru the thin wall
between set screws and the hinge pin.
Tighten after installation to remove slop.
25215
M3
Locknut
x2x2
25188
M3x20mm
BHCS
25188
B4.1 Rear
Hub Plates
(high/low)
x2x2
81642
B4.1 Rear
Hub Plates
(standard)
x2x2
