Associated Electrics RC8B4 - Page 12

12
:: Front Gearbox Build - Bag 5.1, 5.2, 5.3 - Step 4
:: Front Gearbox Build - Bag 5.1, 5.2, 5.3 - Step 5
:: Front Gearbox Build - Bag 5.1, 5.2, 5.3 - Step 3
Center the anti-roll
bar collet on the anti-
roll bar, then tighten
the 3x3mm set
screw.
Front anti-roll
bar gap: 2.0mm
!
!
25225
3x3mm
Set Screw
81585
Anti-Roll
Bar
Collet
81129
(Front) Anti-Roll
Bar, 2.2mm
81260
4x14mm
BHCS
x2
81520
Arm Mount
Insert, Center
81520
Arm Mount
Insert, Center
81567
Arm Mount
B
x2
x2
Kit Setup:
81585
Anti-Roll
Bar Pivot
81512
Anti-Roll
Bar Link
81562
Rod End
Ball
x2
Build left and right side!
Note direction
Note direction
!
!
81260
4x14mm
BHCS
x2
x2
x2
81566
Arm Mount
A
81060
Hinge
Pin
81446
Suspension
Arm Shim
81528
Front Arm,
Lower
89203
3x16mm
BHCS
x2
89317
Droop
Screw
Droop Screw:
Kit Setup:
1.5mm
