Introduction to the Vertical Shaft Impactor
Vertical Shaft Impactor 16
Lid Liners
The lid liners are arranged in
a circular pattern in order to
cover the entire underside of
the lid from wear. The inner
liners and outer lid liners bolt
to the lid with hex head bolts.
Inspection Doors
The lid is equipped with large
inspection doors to facilitate
easy internal inspection and
allows for certain table wear
parts replacement or to check
the feed tube measurement.
If access cannot be gained
through the inspection doors,
the Hydra-Arm can be used to
lift and rotate the lid to open
the crushing chamber.
Hydra-Arm
The optional hydra-arm lifts
the lid for a full 360 degree
access for safe and efcient
maintenance procedures.
Hydra-arm
Hydra-Arm
Lid Liners
