Astralpool APH3 INVERBOOST - Page 48

- 44 -
Part list 68837
NO
ERP
Spare parts
NO
ERP
Spare parts
1
117020183
Controller
41
121000006
4 way valve
2
113712007
Waterproof controller box
42
113030104
4-way valve to exchanger
3
108010075
Controller box
43
112100046
Low pressure switch 0.1-0.3
4
133020043
Fan grill
44
117110021
Discharge temp. sensor T6-TH3
5
132000015
Fan blade
45
112100030
High pressure switch
6
108010024
Fan motor tube
46
113080070
EEV to distribution piping
7
133270007
Top cover
47
113170034
Exchanger to filter
8
112000031
Fan motor
48
120000066
Filter
9
108640010
Fan motor bracket
49
119000021
EEV
10
108640008
Pillar
50
113120021
Liquid storage tank to EEV
11
133020010
Evaporator temperature sensor.
T3-TH2
51
113130016
Filter to Liquid storage tank
12
108640004
Pillar
52
113010206
Gas exhaust
13
117110020
Evaporator temperature sensor.
T3-TH2
53
105000004
Liquid storage tank
14
108640014
Protective mesh baffle
54
112100021-1
Water flow switch
15
103000183
Distribution tube
55
112100021-1
Sealing ring
16
136020005
Rubber fixing block
56
133020026
Rubber ring on water connection
17
103000183
Collective piping
57
133020012
Red rubber ring
18
133270004
Side panel
58
102050004
Water connection sets
19
106000011
Pressure gauge
59
117110011
Water outlet temperature sensor T2-TH5
20
117110004
Coil temperature sensor
60
108010025
Exchanger temperature sensor clip
21
113190001
Clip
61
133020011
Blue rubber ring
22
113190001
Sensor holder
62
117110012
Water inlet temperature sensor T1-TH6
23
110000008
Cable connector
63
102040629
Titanium heat exchanger
24
110000011
Cable connector
64
150000110
Drainage plug
25
110000012
Cable connector
65
108640006
Electric control box cover
26
120000091
globe valve
66
117240002
magnet ring
27
113100008
coupling tool
67
117100047
PCB
28
133270003
Side panel
68
108640015
Electric control box
29
108640003
Electric control box support
69
136020003
Trunking
30
133270006
Bottom plate
70
115000004
5-ways terminal block
31
108640019
Chassis foot
71
136010004
Clip
32
108640021
Base tray
72
117240003
Magnet ring
33
108640020
Chassis foot
73
117010095
Modbus Module
34
101000181
Compressor + damping feet
74
108640016
Module support
35
101000181
Compressor + damping feet
75
136020003
Trunking
36
142000074
Compressor heating resistor
76
117230003
Reactor
37
103000183
Evaporator
77
108640007
Reactor box
38
133270002
Front panel
78
116000074
Low pressure switch 0.2-0.35
39
113020296
Gas return piping
79
142000028
Evaporator heating resistor
40
113060116
4-way valve to gas collect pipe
80
108480015
Evaporator heating resistor support
9
99
.
..
Exploded
ExplodedExploded
Diagram
DiagramDiagram
