Astralpool CONTROL BASIC - Page 3

Code 0000137847 Rev 1.0
2
INSTRUCTION SETTING
Functions:
CALIBRATION
• Press
for 3 Seconds
• Sequence Standard calibration buffer solution 7 and 4 pH or Redox 465mV
SET POINT
• Press:
• hold down
and change the value with key
• 7.4ph
• 750mV
• Press
(together) for 5 Seconds and run Program Setup
PROGRAM
Press
to set the following Item:
• Configuration Pump
! select pH or Redox
• Language
! With the button It’s possible to have 5 language EN, IT, ES, DE, FR
• Flow
! Select with the button
! It’s possible to enable(ON) or disable (OFF) signal input flow (high voltage)
connected in parallel to the recirculation pump.
SETPOINT 7.4ph or 750mV
• Select with the button
and set with
• It’s possible to adjust from 0 to 14 pH value and 0 to 1000 mV for Redox.
SETPOINT TYPE ACID
• Select with the button
and set with
• It’s possible to adjust Acid or Alkaline dosing and High or Low for Redox
