Astralpool PAR56 - Technical Specifications and Compliance; Parts List

ENGLISH
ID. CODE DESCRIPTION 37159 37160 37161 37162 37163 37164 Q
1 33975R0001 Decorative ring X X X 1
07837R0100
Stainless steel ring
XXX1
2 33975R0003 Fixation screw X X X X X X 2
3 00347R0002 Floodlamp base fastening ring X X X X X X 1
4 7020106055 DIN 933 A4 M-6x55 screw X X X X X X 6
5 35604R0500
Underwater led PAR56 12V lamp
XXXXXX1
6 7211100110 110x11 O-ring X X X X X X 1
7 33975R0002 Floodlamp base X X X X X X 1
8 33975R0004 Base srew fixation X X X X X X 2
9 7022106000 Nut DIN 934 A4 M-6 X X X X X X 6
10 35719R0001
Conical joint Ø10.5
XXXXXX2
11 00352R0013 Plastic washer X X X X X X 2
12 07838R0005 Gland seal nut X X X X X X 2
13 33975R0001 Concrete pool Hormigón housing X X 1
13 33976R0001 Prefabricated pool housing with insertions X X 1
14 07838R0012 Gland seal body butt joint X X X X 2
15 07838R0009 Gland seal joint X X X X 1
16 07838R0007 Gland seal body X X X X 1
17 10892R0404 M-25 Socket X X X X 1
18 07838R0008 Housing plug X X X X 1
19 37159R0002 2,5 m 2x1,5 cable XXXXXX1
20 33351R0002 DIN 966 A4 M6x24 screw X X 16
21 00364R0009 Clamp XX1
22 7021448016 DIN 7981 A4 4,8x16 screw X X 2
23 00364R0008 Adhesive joint XX2
FRANÇAIS
ID.
CODE DESCRIPTION 37159 37160 37161 37162 37163 37164 Q
1 33975R0001 Anneau enjoliver X X X 1
1 07837R0100 Anneau enjoliveur Inox X X X 1
2 33975R0003 Vis fixation X X X X X X 2
3 00347R0002 Anneau fixation fond projecteur X X X X X X 1
4 7020106055 Vis DIN 933 M-6x55 X X X X X X 6
5 35604R0500 Lampe immergée à leds PAR 56 12V X X X X X X 1
6 7211100110 Joint torique 110x11 X X X X X X 1
7 33975R0002 Fon projecteur X X X X X X 1
8 33975R0004 Base vis fixation X X X X X X 2
9 7022106000 Vis DIN 934 M-6 X X X X X X 6
10 35719R0001 Joint conique Ø 10,5 X X X X X X 2
11 00352R0013 Rondelle plastique X X X X X X 2
12 07838R0005 Écrou presse-étoupe X X X X X X 2
13 33975R0001 Niche pis. Béton X X 1
13 33976R0001 Niche pis. Préfabriquée avec insertions X X 1
14 07838R0012 Joint plat corps presse-étoupe X X X X 2
15 07838R0009 Joint presse-étoupe X X X X 1
16 07838R0007 Corps presse-étoupe X X X X 1
17 10892R0404 Raccord M-25 X X X X 1
18 07838R0008 Bouchon niche X X X X 1
19 37159R0002 Cáble 2,5 m 2x1,5 X X X X X X 1
20 33351R0002 Vis DIN 966 M6x24 X X 16
21 00364R0009 Bride XX1
22 7021448016 Vis DIN 7981 4,8x16 X X 2
23 00364R0008 Joint adhésif XX2
