Instruction Setting
Functions:
• Calibration (Press Cal Key for 3 Seconds):
o Select the calibration routine pH or Redox by Up or Down key.
o Standard Routine calibration pH probe is 7 and 4 buffer solution and Redox 465 mV buffer
solution
• Set Point (Press Mode Key):
o Press Mode Key and choose SetPoint and adjust value with Up or Down Key before press
Enter and confirm.
! Sp 750mv 700 mv
! Sp 7.4ph 7.6 ph
• Press Cal and Mode Key (both) for 5 Seconds and run Program Setup:
o Program Menu (Press Enter to Mode the following Item)
! Language_ (It’s possible to have 5 language EN, IT, SP, DE, FR)
! Redox Measure
• Setpoint 750 mv (Adjust value with enter and up or down key) It’s possible
to adjust from 0 to 1000 mV value for Redox
• Sp type low (Adjust value LOW or HIGH)
• Ofa time 000 min (Adjust value OFF or set Time)
• Alarm band 000 rx (Adjust value from 100 to 300 mV )
• Type PROP (Adjust value between OFF, PROP, ON/OFF or TIMED)
(only if set to Timed there are two new entries to make a dosage cycles ON
/ OFF selectable)
! Timed ON (Change the value from 1 to 120 minutes)
! Timed OFF (Change the value from 1 to 120 minutes)
! ph Measure
• Setpoint 7.4ph (Adjust value with enter and up or down key) It’s possible to
adjust from 0 to 14 pH value.
• Sp type acid (Adjust value ACID or ALKA)
• Ofa time 000 min (Adjust value OFF or set Time)
• Alr band 000 ph (Adjust value from 1 pH to 3 pH)
• Temp 25*C(Adjust value with enter and up or down key) pH measure only.
• Type PROP (Adjust value between OFF, PROP or ON/OFF )
! Flow (Adjust value with enter and up or down key Enable or Disable)
• It’s possible to enable(ON) or disable (OFF) signal input
! Calibration probe (Adjust value with enter and up or down key)
• Full (pH 7 and 4, Redox 465 mV buffer solution)
• Easy (pH 7, Redox 465 mV buffer solution)
• Off (Disabled)
! Password (Adjust value with enter and up or down key, standard value 0000)
• Save and escape Program setup with ESC key
o Exit save (Adjust value with up or down key and confirm with enter key)
• Priming Pump Keep Press UP Key for 1 seconds and priming redox pump
o priming 700mv
• Priming Pump Keep Press Down Key for 1 seconds and priming pH pump
o priming 7.2ph
• Lock pump function
o Press Up and Enter (both) after 5 second flash Rx Stop press again to unlock
o Press Down and Esc (both) after 5 second flash pH Stop press again to unlock
• The unit doses in proportional mode respect at Set Point (minimum distance 25%, maximum
distance 90% of 10 minutes time period dosing)
Note: The unit in program menu to go out in automatic mode after 1 minutes of wait time, the unit
doesn’t save nothing.
