Astralpool PROELYXP09i - Page 52

- 59 -
9.12 Spare parts list: 71683
NO
ERP
Parts name
NO
ERP
Parts name
1
133100001
Top cover
41
117020180
Controller
2
117110020
Ambient temp. sensor T5-TH1
42
113712007
Waterproof controller box
3
133020010
Ambient temp. sensor clip
43
103000209
Evaporator pipe
4
133250003
Back panel
44
136020005
Rubber block
5
103000209
Evaporator
45
113020389
Gas return piping
6
117110004
Evaporator temperature sensor T3-TH2
46
116000073
Low pressure switch
7
113100009
Clip
47
113060083
4 way valve to collective piping
8
113100009
Sensor holder
48
113010228
Discharge pipe
9
103000209
Distribution piping
49
113030087
4 way valve to exchanger
10
108120036
Isolation panel
50
121000009
4 way valve
11
117230001
Reactor
51
116000008
High pressure switch
12
108120035
Pillar
52
117110021
Discharge temp. sensor T6-TH3
13
108120034
Top frame
53
113120020
Pipe to evaporator
14
108120044
Fan motor bracket
54
113130020
Pipe to dehydrator filter
15
108480015
Evaporator heating resistor support
55
113080055
EEV to distribution piping
16
142000079
Evaporator heating resistor
56
119000042
EEV
17
108550009
Pillar
57
120000066
Dehydrator filter
18
112000031
Fan motor
58
113170028
Dehydrator filter pipe
19
132000015
Fan blade
59
112100021-1
Water flow switch
20
108010024
Fan shaft cover
60
117110011
Water outlet temp. sensor T2-TH5
21
133250004
Left side panel
61
108010025
Exchanger temperature sensor clip
22
133250001
Front panel
62
102040754
Titanium heat exchanger
23
108010014
Fan grill
63
113900082
Water connection sets
24
120000091
Globe valve
64
133020012
Blue rubber ring
25
113100008
Copper pipe
65
133020026
Rubber ring on water connection
26
101000186
Compressor + damping feet
66
117110012
Water inlet temp. sensor T1-TH6
27
101000186
Compressor + damping feet
67
150000110
Drainage plug
28
105000008
Liquid storage tank
68
133020011
Red rubber ring
29
142000077
Compressor Heating resistor
69
136020083
Sealing ring
30
108470069
Base tray
70
108120040
Electric box cover
31
108550008
Handle pillar
71
117140016
Driver board
32
108010065
Terminal Board
72
142000038
Relay
33
133250002
Right panel
73
117260001
Filter board
34
115000025
3-ways terminal for electricity
74
117240002
Magnet ring
35
106000011
Pressure gauge
75
117250007
PCB
36
136010004
Clip
76
108120038
Electric box
37
108550006
Pillar
77
117240003
Magnet ring
38
115000027
3-ways terminal for filtration pump
78
117010095
Modbus module
39
133250005
Terminal blocks plastic cover
79
108120039
Scale board
40
133030011
Wiring box
