To Next PageTo Next PageWhat to do if my Astralpool Heat Pump has a gas return sensor failure?
If your Astralpool Heat Pump shows a gas return sensor failure, it could be due to the sensor being in an open or short circuit, or the wiring of the sensor being loose. Check or change the sensor and re-fix the wiring of the sensors.
What to do if my Astralpool PROELYXP09i Heat Pump shows a water flow failure TS1?
If your Astralpool Heat Pump displays a water flow failure TS1, it could be due to a damaged water flow switch or insufficient water flow. Try replacing the water flow switch or checking the filtration pump and waterway system to ensure adequate water flow.
Why is my Astralpool PROELYXP09i showing compressor current protection?
Compressor current protection in your Astralpool Heat Pump can occur due to several reasons: the compressor current being too large instantaneously, incorrect connection for compressor phase sequence, compressor accumulations of liquid and oil, a damaged compressor or driver board, abnormal water flow, or power fluctuations. To resolve this, check the compressor, compressor phase, power range, phase sequence connection, the waterway system and filtration pump, and mains power input.
What causes T6 exhaust too high protection in Astralpool PROELYXP09i Heat Pump?
T6 exhaust too high protection in your Astralpool Heat Pump can result from a lack of gas, low water flow, a blocked piping system, or a faulty exhaust temperature sensor. Address this by checking the high-pressure gauge and filling with gas if needed, inspecting the waterway system and filtration pump, checking the piping system for blockages, and replacing the exhaust temperature sensor.
What to do if my Astralpool Heat Pump has an ambient temperature sensor failure T5?
If your Astralpool Heat Pump shows an ambient temperature sensor failure T5, it could be due to the sensor being in an open or short circuit, or the wiring of the sensor being loose. Check or change the sensor and re-fix the wiring of the sensors.
What to do if my Astralpool PROELYXP09i Heat Pump has an exhaust piping sensor failure T6?
If your Astralpool Heat Pump shows an exhaust piping sensor failure T6, it could be due to the sensor being in an open or short circuit, or the wiring of the sensor being loose. Check or change the sensor and re-fix the wiring of the sensors.
What to do if my Astralpool PROELYXP09i Heat Pump shows IPM module temperature too high protection?
If your Astralpool Heat Pump displays an IPM module temperature too high protection error, it could be due to an output exception of the IPM module thermal circuit, an abnormal or damaged motor, or a broken fan blade. Try changing the driver board, checking if the fan motor speed is too low or fan motor is damaged, or changing the fan blade.
What causes PFC module protection in Astralpool PROELYXP09i?
PFC module protection in your Astralpool Heat Pump can be triggered by an output exception of the PFC module, an abnormal or damaged motor, a broken fan blade, or abnormal input power. To solve this, change the driver board, check if the motor speed is too low or fan motor is damaged, change the fan blade, or check the input voltage.
What does 'low ambient temperature protection' mean for my Astralpool Heat Pump?
The 'low ambient temperature protection' message on your Astralpool Heat Pump indicates that the unit is either being used outside of its intended environment or that there is a sensor abnormality. Stop using the unit if it is beyond its operating scope, or change the sensor.
How to resolve communication failure between Main control board and Driving board in Astralpool Heat Pump?
A communication failure between the Main control board and Driving board in your Astralpool Heat Pump is likely caused by a poor connection of the communication wire or a damaged wire. Check the wire connection and replace the wire if necessary.
General| Brand | Astralpool |
|---|---|
| Model | PROELYXP09i |
| Category | Heat Pump |
| Language | English |
Presents detailed technical specifications and performance data.
Lists general technical specifications like compressor type, voltage, and current.
Guidelines for selecting the optimal installation location for the unit.
Procedure for starting up the heat pump for the first time.
Details the logic for heating operation based on water temperature.
Details the logic for cooling operation based on water temperature.
Lists error codes, reasons, and solutions for controller displays.
Explains protection mechanisms for overheating and overcooling.
Addresses malfunctions without error codes on the controller.
