9.16 Spare parts list: 68823
NO
ERP
Parts Name
NO
ERP
Parts Name
1
133100001
Top cover
41
113050110
Collective piping
2
117110020
Ambient temp. sensor T5-TH1
42
113170028
Degydrator filter pipe
3
133020010
Ambient temp. sensor clip
43
120000066
Dehydrator filter
4
133250003
Back panel
44
119000022
EEV
5
103000154
Evaporator
45
113080055
EEV to distribution piping
6
117110004
Evaporator temperature sensor
T3-TH2
46
113120020
Pipe to evaporator
7
113190001
Clip
47
113030087
4 way valve to exchanger
8
113190001
Sensor holder
48
117110021
Discharge temp. sensor T6-TH3
9
113040102
Distribution piping
49
116000008
High pressure switch
10
108550010
Isolation panel
50
121000009
4 way valve
11
117230002
Reactor
51
120000023
Suction valve
12
108120034
Top frame
52
113010158
Discharge pipe
13
108120035
Pillar
53
116000080
Low pressure switch 0.2-0.35
14
108120037
Fan motor bracket
54
116000079
Low pressure switch 0.1-0.3
15
112000031
Fan motor
55
113020245
Gas return piping
16
108010024
Fan motor pipe cover
56
113060083
4-way valve to collective piping
17
132000015
Fan blade
57
113130015
Pipe to dehydrator filter
18
133250004
Left side panel
58
113900082
Water connection sets
19
133250001
Front panel
59
133020011
Red rubber ring
20
108010014
Fan grill
60
133020026
Rubber ring on water connection
21
108550009
Pillar
61
112100021-1
Water flow switch
22
108550005
Base tray
62
116000001-2
Sealing ring
23
101000149
Compressor + damping feet
63
117110011
Water outlet temp. sensor T2-TH5
24
105000008
Liquid storage tank
64
108010025
Exchanger temperature sensor clip
25
142000077
Compressor Heating resistor
65
113900082
Water connection sets
26
101000149
Compressor + damping feet
66
133020012
Blue rubber ring
27
108550008
Handle pillar
67
102040502
Titanium heat exchanger
28
108010065
Terminal Board
68
117110012
Water inlet temp. sensor T1-TH6
29
110000008
Wire connection
69
150000110
Drainage plug
30
108010018
Wiring box
70
108120040
Electric box cover
31
133250002
Right panel
71
117140003
Driver board
32
115000006
3-ways terminal for electricity
72
108120038
Electric box
33
110800001
Pressure gauge
73
108120039
Scale board
34
136010004
Clip
74
117260002
Filter board
35
108550006
Pillar
75
117250001-V1.5
PCB
36
115000027
3-ways terminal for water pump
76
117240002
Magnet ring
37
133250005
Terminal blocks plastic cover
77
117240003
Magnet ring
38
113712007
Waterproof controller box
78
117010095
Modbus module
39
117020150
Controller
79
142000038
Relay
40
136020005
Rubber block
80
N/A
N/A
81
117140006
Fan motor driver board
