6.6 Electrical connection
The power supply for the heat pump must come, preferably, from an exclusive circuit with regulatory protection
components (30mA differential protection) and a magneto-thermal switch.
- The electrical installation must be carried out by a specialized professional (electrician) in accordance with the
standards and regulations in force in the country of installation.
- The heat pump circuit must be connected to a safety earth circuit at the terminal block.
- The cables must be properly installed to prevent interference.
- The pump is intended for connection to a general power supply with earth connection.
- Section of the cable; This section is indicative and should be checked and adapted according to the needs and
conditions of use.
- The tolerance of acceptable voltage variation is +/- 10% during operation.
The connections must be dimensioned according to the power of the device and the state of installation.
Models
Circuit breaker
Maximum length of the wire
2,5 mm²
4 mm²
6 mm²
10 mm²
PROELYXP07i
7 A
84 m
135 m
200 m
335 m
PROELYXP09i
9 A
57 m
90 m
130 m
225 m
PROELYXP11i
11A
PROELYXP14i
14 A
43 m
68 m
100 m
170 m
PROELYXP16i
16 A
34 m
54 m
80 m
135 m
PROELYXP20i
20 A
29 m
45 m
66 m
110 m
PROELYXP26i
26 A
135 m
210 m
315 m
525 m
PROELYXP30i
35 A
21 m
34 m
49 m
84 m
PRO ELYO INVERBOOST NN 26T
9 A
57 m
90 m
130 m
225 m
PRO ELYO INVERBOOST NN 35
34 A
21 m
34 m
49 m
84 m
PRO ELYO INVERBOOST NN 35T
13 A
-
27 m
39 m
68 m
These values are given as a guideline, only an authorized electrician can determine the values
corresponding to your installation.
The electric cable must be equipped with a ground connection and with a circuit breaker with
differential 30mA.
