Astralpool PROELYXP14i - Parameter Checking

- 34 -
Parameter checking:
Press first, then press to check the User parameter from d0 to d14
Code
Condition
Scope
Remark
d0
IPM mould temperature
0-120℃
Real testing value
d1
Inlet water temp.
-9℃～99℃
Real testing value
d2
Outlet water temp.
-9℃～99℃
Real testing value
d3
Ambient temp.
-30℃～70℃
flash if Real value<-9
d4
Frequency limitation code
0,1,2,4,8,16
Real testing value
d5
Piping temp.
-30℃～70℃
flash if Real value<-9
d6
Gas exhaust temperature
0℃～C5℃ (125℃)
Real testing value
d7
Step of EEV
0～99
N*5
d8
Compressor running frequency
0～99Hz
Real testing value
d9
Compressor current
0～30A
Real testing value
d10
Current fan speed
0-1200 (rpm)
Real testing value
d11
Error code for last time
All error code
d12
MOBUS COM
0 - 5
Setting, Modbus Only
d13
MODBUS ID Address
1 - 88
Setting, Modbus Only
d14
Product Code
0000- FFFF
Setting, Modbus Only
Remark:
d4:Frequency limitation code,
0: No frequency limit; 1:Coil pipe temperature limit;
2: Overheating or overcooling frequency limit; 4:Drive Current frequency limit;
8:Drive voltage frequency limit; 16:Drive high temperature frequency limit
Press first, then press to check/adjust the User parameter from P1 to P7
Code
Name
Scope
Default
Remark
P0
Mandatory defrosting
0-1
0
0: Default normal operation
1: mandatory defrosting.
P1
Working mode
0-1
1
1:Heating mode, 0:cooling mode,
P2
Timer on/off
0-1
0
1 Timer on/off is under function
，
0 Timer on/off is out
of function (The setting of P5 and P6 won’t work)
P3
Water pump
0-1
0
1:Always running;
0:Depends on the running of compressor
P4
Current time
HH:MM
00：00
0-23:0-59
P5
Timer on
HH:MM
00：00
0-23:0-59
P6
Timer off
HH:MM
00
：
00
0-23:0-59
P7
Water temp. calibration
-9
～
9
0
Default setting: 0
P12
MOBUS COM
0 - 5
0
Modbus Only（default value after reset）
P13
MODBUS ID Address
1 - 88
9
Modbus Only（default value after reset）
