Astralpool PROELYXP14i - Page 48

- 55 -
9.8 Spare parts list: 71680
NO
ERP
Spare parts name
NO
ERP
Spare parts name
1
1332600011
Top cover
37
1332600041
Right panel
2
1332600021
Back panel
38
103000230
Distribution piping assembly
3
117110020
Ambient temp. sensor T5-TH1
39
136020005
Rubber block
4
133020010
Ambient temp. sensor clip
40
103000230
Collective piping assembly
5
103000230
Evaporator
41
113020338
Gas return piping
6
113100009
Sensor holder
42
116000073
Low pressure switch
7
113100009
Clip
43
113130021
Pipe to dehydrator filter
8
117110004
Evaporator temperature
sensor T3-TH2
44
120000066
Filter
9
117230002
Reactor
45
113060122
4 way valve to collective piping
10
108560003
Pillar
46
116000068
High pressure switch
11
108560002
Top frame
47
113010244
Discharge pipe
12
108480015
Evaporator heating resistor
support
48
117110021
Discharge temp. sensor T6-TH3
13
142000079
Evaporator heating resistor
49
121000006
4 way valve
14
108560011
Fan motor bracket
50
113170032
Exchanger to Filter
15
112000031
Fan motor
51
113120019
Pipe to evaporator
16
132000023
Fan blade
52
113030108
4 way valve to exchanger
17
1332600051
Left side panel
53
119000021
EEV
18
1332600031
Front panel
54
113080056
EEV to distribution piping
19
108170017
Fan grill
55
150000110
Drainage plug
20
108560036
Base tray
56
108010025
Exchanger temperature sensor clip
21
101000185
Compressor + damping feet
57
117110012
Water inlet temp. sensor T1-TH6
22
101000185
Compressor + damping feet
58
133020026
Rubber ring on water connection
23
142000077
Compressor Heating resistor
59
133020011
Blue rubber ring
24
105000004
Liquid storage tank
60
102040703
Titanium heat exchanger
25
108560010
Isolation panel
61
113900082
Water connection sets
26
120000091
Globe valve
62
117110011
Water outlet temp. sensor T2-TH5
27
108560034
Globe valve support
63
136020083
Sealing ring
28
113100008
Copper pipe
64
112100021-1
Water flow switch
29
108010065
Terminal Board
65
133020012
Red rubber ring
30
133030011
Wiring box
66
117010095
Modbus module
31
136010004
Clip
67
117240002
Magnet ring
32
106000011
Pressure gauge
68
117240003
Magnet ring
33
1332500051
Terminal blocks plastic cover
69
108560012
Electric box
34
115000004
5-ways terminal block
70
117100048
PCB
35
117020180
Controller
71
108540006
Electric box cover
36
113712007
Waterproof controller box
