InstallationandGeneralMaintenanceManual–VironP300PoolPump
x For230V,useaH07RNͲF3typeconnectionsleevewithacablesectionthatadaptsto
thepowerofthemotorandlengthfthecable.
x ForAC,useaH07RNͲF3typeconnectionsleevewithacablesectionthatadaptstothe
powerofthemotorandthelengthofthecable.
x Themainscablemustonlybeconnectedbyskilled,authorisedpersonnel.
Ͳ Beforeconnectingthemotor,checkthetypeoffuserequired.
Ͳ Checkthecorrectlayoutandconnectionoftheearthingcableintheequipment.
Ͳ Respecttheelectricalinstallationandconnectionconditions.Failuretodosomaylead
tothepumpmanufacturerdecliningallresponsibilityandrenderingtheguaranteenull
andvoid.
Ͳ ThemotorsaresubjecttotheEECstandardswiththeIPX5protection.
Ͳ Specialregulationsmayexistfortheinstallation.
Ͳ Unsuitablemainsconnectionsinvolvetheriskofdeath.
ͲAmeansofdisconnectionmustbeincorporatedinfixedwiringinaccordancewithwiring
rules.Thedisconnectdeviceshouldhaveacontactseparationinallpolesthatprovide
fulldisconnectionundercategoryIIIconditions.

Thisappliancemustbeinstalledbyaqualifiedservicetechnical.Wheninstallingtheappliance
ensureallpartsareinstalledinthecorrectzoneinaccordancewiththewiringrules.Inparticular
refertoEN60364(EU).
 
Fig.1
VERANKERUNG / DETALHE DE FIXACAO
DETALL E ANCLAJE / DETTAGLIO ANCORAGGIO
ANCHOR DETAI L / DETAIL DE L' ANCRAGE

Fig.2
