ASUNA 4500 - Assembly Parts List

Assembly Parts List
4
#A1 Main Frame
#B3 Pedal - 2 pcs
#B9 Saddle - 1 set
#A4 Slide track - 1 set
#1 Carriage Bolt M8 x 90L - 2 pcs
#2 M8 Dome Nut - 2 pcs
#10 Shaft 1/2" - 4 pcs
#27 Flat Washer 8 x 16 - 2 pcsØ Ø
#12 3/8" Nylon Nut - 1 pc
#11 Bolt 3/8" x 120L - 1 pc
#30 Flat Washer 13 x 25 - 1 pcØ Ø
#A2 Front Stabilizer - 1 set
Tools
#C2 Pop Pin - 1 pc
#C1 Fixed Knob - 1 pc
21
T4
14
T3
M6
T1
14
13
T2
- 1 set
