ASURITY CP-22LP - Operation and Status; Testing Float Operation; Testing Overflow Switch

ASURITY
TM
CONDENSATE MANAGEMENT PAGE
10
OPERATION
1. TESTING FLOAT
Manually ll the tank with water. An amber LED will indicate pump is
operating.
2. TESTING OVERFLOW SWITCH (IF CONNECTED)
Manually overll tank with water. If overow safety switch is wired
correctly, appliance will shut down, condensate pump will pump out
water, and a red LED will illuminate.
1
2
1
2
1
2
2
