ASURITY
TM
CONDENSATE MANAGEMENT PAGE
4
PACKAGE CONTENTS
SPECIFICATIONS
PART DESCRIPTION QUANTITY
A Condensate Pump 1
B Inlet Hole Covers 3
CP-22LP CP-22LP-230
Rated Voltage 120 Volts/60Hz 220 Volts/60 Hz
Rated Current Draw 1.9 Amps 1.0 Amps
Head Height 22 ft. maximum 22 ft. maximum
Flow Rate at Zero
Head
1.6 GPM 1.0 GPM
Product Weight 4.7 lbs. 4.7 lbs.
Inlet Height from Base 1.75 in. 1.75 in.
Inlet Hole Cover
A
B
To Next Page
