4-28
Chapter 4: BIOS Setup
CPU Multiplier [11.0]
Allows you to manually set the CPU speed. The configuration options vary
depending on the speed of the processor installed. This item appears only
when the CPU Speed/Voltage Setting item is set to Manual.
CPU Voltage [1.450 V]
Allows you to manually set the CPU voltage. The configuration options
vary depending on the speed of the processor installed. This item appears
only when the CPU Speed/Voltage Setting item is set to Manual.
The following item appears only when the AI Overclocking field is set
to Adaptive Overclocking.
AGP/PCI Frequency (MHz) [Auto]
Sets the AGP/PCI frequency.
Configuration options: [Auto] [66.66/33.33] [75.4/37.7]
DDR Voltage [Auto]
Allows you to automatically detect or select from a list the DDR operating
voltage. Configuration options: [Auto] [2.6V] [2.7V] [2.8V]
AGP Voltage [1.5V]
Adjusts the AGP voltage setting.
Configuration options: [1.5V] [1.6V]
V-Link Voltage [2.5V]
Adjusts the V-Link voltage setting. Configuration options: [2.5V] [2.6V]
Setting a low CPU voltage can cause system boot failure!
