Asus DSL-N14U B1 User Manual

23
Creating your Guest Network
Setting up a Guest Network provides wireless Internet
connectivity for temporary visitors while restricting access to your
private network.
To create your guest network:
1. Click Guest Network on the left navigation panel.
2. Click Enable.
3. To configure additional options, click any of the items listed.
e8760_dsl-n14u_manual.indd 23 12/23/13 9:18:12 AM

Asus DSL-N14U B1 Specifications

General

Device Type	Wireless Router
Frequency Band	2.4 GHz
Maximum Wireless Speed	300 Mbps
LAN Ports	4 x 10/100 Mbps
ADSL2+	Yes
USB Ports	1 x USB 2.0
DHCP Server	Yes
Security	WPA/WPA2
VPN Support	PPTP, L2TP, IPSec
Antennas	2 x External
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 70 °C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Wireless Standard	IEEE 802.11b/g/n
Firewall	SPI Firewall
