Reset button
This button resets or restores the system to its factory default settings.
Power switch
Press to power on or off the system.
Power (DC-In) port
Insert the bundled AC adapter into this port and connect your router to a
power source.
USB 2.0 port
Insert a USB 2.0 device such as a USB hard disk or USB flash drive into this
port.
LAN 1~4 ports
Connect network cables into these ports to establish LAN connection.
ADSL port
Connects to a splitter or to a telephone outlet via an RJ-11 cable.
WPS button*
This button launches the WPS Wizard.
* The WPS button can be used as a WiFi button by changing the settings in
the Advanced Settings > Administration page.
Rear features
