Hardware Technical Specification
5-37
7.3 Main board
7.3.1 Main system module spec
Feature: CPU Celeron M, NB 910GML, SB ICH6M,
Clock generator,
SO-DIMM
PC/AT compatible system (RTC, DMA, INT,
Timer, … etc)
IDE controller with PIO Mode 4 & Ultra-33/66/100,
PCMCIA /Cardbus controller & their sockets
Audio CODEC,
Audio amplifier,
CPU thermal sensor,
I/O connectors,
Power management control circuit,
Internal Graphic/Display controller,
Keyboard Controller,
Audio analog signal,
Power control, DC/DC,
Battery power
Regulated power
SM bus for Battery
Indication Charger LED
Indication Power LED
Indication WLAN LED
Indication FLASN Access LED
…etc
