H81-PLUS specications summary
(continued on the next page)
CPU LGA1150 socket for 4th Generation Intel
®
Core
TM
i7/i5/i3, Pentium
®
,
Celeron
®
Processors
Supports Intel
®
22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H81 Express Chipset
Memory 2 x DIMM, max. 16GB, DDR3 1600 / 1333 / 1066 MHz, non-ECC, un-
buffered memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
Please refer to the Memory QVL (Qualied Vendors List) for details.
** Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
*** Due to Intel
®
chipset limitation, the DDR3 1600MHz and higher memory
modules on XMP mode will run at the maximum transfer rate of DDR3 1600MHz.
Graphics VGA output support: RGB port
- Supports RGB with max. resolution of 1920 x 1200 @60Hz
Supports Intel
®
InTru
TM
3d/Quick Sync Video/Clear Video HD Technology/
Insider
TM
Maximum shared memory of 1024 MB
Expansion slots 1 x PCI Express x16 slot (at x16 mode, yellow)
2 x PCI Express x1 slots
3 x PCI slots
Storage Intel
®
H81 Express Chipset:
- 2 x Serial ATA 6.0 Gb/s connector (yellow)
- 2 x Serial ATA 3.0 Gb/s connector (dark brown)
- Support Intel
®
Rapid Start Technology* and Intel
®
Smart Connect
Technology**
* Due to the limitation of the Intel
®
H81 chipset, Intel
®
Rapid Start Technology can
be congured only from the BIOS Setup Program.
** Intel
®
Rapid Start Technology and Intel
®
Smart Connect Technology will work
depending on the CPU installed.
Package contents
Check your motherboard package for the following items.
Motherboard ASUS H81-PLUS motherboard
Cables 2 x Serial ATA 6.0 Gb/s cables
Accessories 1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
