H81-PLUS specications summary
Rear panel I/O
ports
1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
1 x RGB port
1 x LAN (RJ-45) port
2 x USB 3.0/2.0 ports (blue)
2 x USB 2.0/1.1 ports
1 x COM port
1 x LPT port
3 x Audio jacks support 8-channel audio output
Internal
connectors/
switches/
buttons
3 x USB 2.0/1.1 connectors support additional 6 USB 2.0 ports
2 x SATA 6.0 Gb/s connectors
2 x SATA 3.0 Gb/s connectors
1 x CLRTC jumper
1 x 4-pin CPU fan connector
1 x 4-pin Chassis fan connectors
1 x Front panel audio connector (AAFP)
1 x System panel connector
1 x S/PDIF Header
1 x 24-pin EATX power connector
1 x 4-pin EATX 12V power connector
BIOS features 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI v2.0, WfM2.0, SM BIOS v2.7, ACPI
v4.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, My
Favorites, Quick Note, Last Modied log, F12 PrintScreen, F3 Shortcut functions
Manageability
WfM 2.0, DMI 2.0, WOL by PME, PXE
Support DVD Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
Operating
System
Support
Windows
®
8 / Windows
®
7
Form factor
ATX form factor: 12.0”x 7.4” (30.5cm x 18.8cm)
Specications are subject to change without notice.
