H81M series specications summary
CPU LGA1150 socket for Intel
®
4th Generation Core
TM
i7/ i5 / i3, Pentium
®
and
Celeron
®
Processors
Supports 22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H81 Express Chipset
Memory 2 x DIMMs, max. 16GB DDR3 1600/1333/1066MHz, non-ECC, unbuffered
memory modules
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual
CPUs. Please refer to Memory QVL for details.
** Refer to
www.asus.com for the latest Memory QVL (Qualied Vendors List).
*** Due to Intel
®
chipset limitations, DDR3 1600MHz and higher memory modules
on XMP mode will run at the maximum transfer rate of DDR3 1600MHz.
Graphics Integrated Graphics Processor - Intel
®
HD Graphics support
Multi-VGA output support: HDMI/DVI-D/RGB port (H81M-A model)
Multi-VGA output support: DVI-D/RGB port (H81M-E model)
- Supports HDMI with max. resolution up to 4096x2160@24Hz /
2560x1600@60Hz (H81M-A model)
- Supports DVI-D with max. resolution up to 1920 x1200@60Hz
- Supports RGB with max. resolution 1920x1200@60Hz
- Maximum shared memory of 1024MB
Expansion slots 1 x PCI Express x16 slot (at x16 mode, yellow)
2 x PCI Express x1 slots
Storage
Intel
®
H81 Express Chipset:
- 2 x Serial ATA 6.0 Gb/s connectors (yellow)
- 2 x Serial ATA 3.0 Gb/s connectors (dark brown)
- Supports Intel
®
Rapid Start Technology* and Intel
®
Smart Connect
Technology**
* Due to the limitation of the Intel
®
H81 chipset, Intel
®
Rapid Start Technology can
be congured only from the BIOS Setup program.
** These functions will work depending on the CPU installed.
Package contents
Check your motherboard package for the following items.
Motherboard ASUS H81M Series motherboard
Cables 2 x Serial ATA 6.0 Gb/s cables
Accessories 1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
