Asus M2N-E SLI - Front Panel Audio Connector; Digital Audio Connector

ASUS M2N-E SLI 2-29
8. Front panel audio connector (10-1 pin FP_AUDIO)
This connector is for a chassis-mounted front panel audio I/O module
that supports either HD or legacy AC ‘97 audio standard. Connect one
end of the front panel audio I/O module cable to this connector.
R
M2N-E SLI
M2N-E SLI Front panel audio connector
FP_AUDIO
Line out_L
BLINE_OUT_L
MIC2
NC
MICPWR
BLINE_OUT_R AGND +5VA
R
M2N-E SLI
M2N-E SLI Digital Audio Connector
+5V
SPDIFOUT
GND
SPDIF_OUT
9. Digital audio connector (4-1 pin SPDIF)
This connector is for an additional Sony/Philips Digital Interface (S/
PDIF) port(s). Connect the S/PDIF Out module cable to this connector,
then install the module to a slot opening at the back of the system
chassis.
The S/PDIF module is purchased separately.
