Asus M2N-VM DH User Guide

3-12
3.3.4 Setting up the station mode
Open the setup utility by double-clicking the utility icon on the desktop. A
message pops up asking you to set up the station mode via the Windows
®
Wireless Zero Conguration (WZC) service.
To congure the Windows
®
Wireless Zero Conguration (WZC) service, follow the
instruction below to make the settings.
2. A window prompts out asking
you for the key if you have set
up encryption on your wireless
router, input the keys and click
Connect
. The connection is
complete.
1. Double-click the wireless network
icon on the task bar to view
available networks.Select the AP
and click
Connect
.
The actual screens of Windows
®
Wireless Zero Conguration service may differ
according to the Operating System (OS) of your computer.

Asus M2N-VM DH Specifications

General

ECC	No
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
Maximum number of SMP processors	1
USB 2.0 connectors	2
S/PDIF out connector	Yes
Number of SATA connectors	5
I/O ports	1x WiFi-AP Solo antenna
Special features	ASUS WiFi-AP Solo Asus DH Remote ASUS MP3-In ASUS C.P.R. Q-Fan2 MyLogo2 EZ Flash 2
Manageability features	WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE, Chassis Intrusion
Controller interface type	JMicron JMB363
Controller 2nd interface type	NVIDIA nForce 430
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	ADI AD1988
Power source type	ATX
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Bundled software	Drivers ASUS DH Remote Application ASUS WiFi-AP Solo Wizard Nvidia MediaShield RAID ASUS PC Probe 2 AMD Cool ' n' Quiet Utility ASUS LiveUpdate Utility Anti-Virus software (OEM)
Graphics card	GeForce 6100
Networking features	Gigabit Ethernet, Wireless LAN
BIOS memory size	32 Mbit
RAID levels	0, 1, 0+1, 5, JBOD

Weight and Dimensions

Width	245 mm
