4-22 Chapter 4: BIOS setup
4.4.2 AI NET2
F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select Sub-menu F10: Save and Exit
Select Menu
Item Specic Help
Enable or Disable LAN
cable check during
POST.
AI Net2
POST Check LAN Cable [Disabled]
POST Check LAN2 Cable [Disabled]
Pair Status Length
LAN1(1-2) Open N/A
LAN1(3-6) Open N/A
LAN1(4-5) Open N/A
LAN1(7-8) Open N/A
LAN2(1-2) Open N/A
LAN2(3-6) Open N/A
LAN2(4-5) Open N/A
LAN2(7-8) Open N/A
Phoenix-AwardBIOS CMOS Setup Utility
Advanced
POST Check LAN Cable [Disabled]
POST Check LAN2 Cable [Disabled]
Enables or disables checking of the LAN/LAN2 cable during the Power-On
Self-Test (POST). Conguration options: [Disabled] [Enabled]
NB to SB HT Voltage [Auto]
Allows you to set the NB to SB HT voltage.
Configuration options: [Auto] [+1.300V] [+1.325V] [+1.350V]~[+1.500V]
NB Core/PCI-E Voltage [Auto]
Allows you to set the NB Core/PCI-E voltage.
Conguration options: [Auto] [+1.200V] [+1.250V] [+1.300V] [+1.350V]
[+1.400V]
SB Core/PCI-E Voltage [Auto]
Allows you to set the Southbridge core/PCI Express voltage.
Configuration options: [Auto] [+1.500V] [+1.525V] [+1.550V]~[+1.700V]
[+1.750V]
SB Standby Core Voltage [+1.50V]
Allows you to set the Southbridge +1.5V standby voltage.
Configuration options: [+1.50V] [+1.60V] [+1.70V]
