Asus M2N68 SE User Manual

1.5 Motherboard overview
1.5.1 Placement direction
When installing the motherboard, ensure that you place it into the chassis in the correct
orientation. The edge with external ports goes to the rear part of the chassis as indicated in
the image below.
1.5.2 Screw holes
Place six (6) screws into the holes indicated by circles to secure the motherboard to the
chassis.
Do not overtighten the screws! Doing so can damage the motherboard.
M2N68 SE
Place this side towards
the rear of the chassis.
Chapter 1: Product introduction 1-5

Asus M2N68 SE Specifications

General

Form Factor	ATX
Chipset	NVIDIA GeForce 7025 / nForce 630a
Socket	AM2
Memory Type	DDR2
Maximum Memory	4 GB
Memory Slots	2 x DIMM
PS/2	2
Expansion Slots	1 x PCIe x16, 2 x PCIe x1
Storage Interface	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-channel
LAN	Realtek RTL8201CL
USB Ports	8 x USB 2.0 (4 rear, 4 internal)
