ASUS M3N78-VM 1-25
Audio 2, 4, 6, or 8-channel conguration
11. USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus (USB) ports
are available for connecting USB 2.0 devices.
12. External SATA port. These port connect to an external Serial ATA hard
disk drive. To congure a RAID0, RAID1, RAID 0+1, RAID 5, or JBOD set,
connect external Serial ATA hard disk drives to the External SATA port.
Port Headset
2-channel
4-channel 6-channel 8-channel
Light Blue Line In Line In Line In Line In
Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Mic In Mic In
Orange – – Center/Subwoofer Center/Subwoofer
Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out
Gray – – – Side Speaker Out
Refer to the audio conguration table below for the function of the audio ports in
2, 4, 6 or 8-channel conguration.
• To use hot-plug, set the SATA Mode Select in the BIOS settings to [AHCI
Mode]. See section 2.3.5 Storage Conguration for details.
• When the AHCI mode is turned on, SATA 1/2/3/5/6 and eSATA are all in
AHCI mode, and DOS cannot detect HDD in drivers installation.
13. DVI port. This port is for any DVI-D compatible device. DVI-D can’t be
converted to output RGB Signal to CRT and isn’t compatible with DVI-I.
14. HDMI port. This port is for a High-Denition Multimedia Interface (HDMI)
connector, and is HDCP compliant allowing playback of HD DVD, Blu-Ray
and other protected content.
• This motherboard comes with dual-VGA output. If you connect 2 monitors
to both VGA and DVI-D / HDMI out ports, each controller can drive same or
different display contents to different resolutions and refresh rates.
• Due to the chipset limitation, simultaneous output for DVI and HDMI is not
supported.
• To play HD DVD or BLU-Ray Disc, ensure to use an HDCP compliant
monitor.
