2-24 Chapter 2: BIOS setup
tRWTTO [ Auto]
Allows you to set tRWTTO. Conguration options: [Auto] [2 CLK] [3 CLK] [4
CLK] [5 CLK] [6 CLK] [7 CLK] [8 CLK] [9 CLK]
tWRRD [ Auto]
Allows you to specify the write to read delay when accessing different
DRAMs. Conguration options: [Auto] [0 CLK] [1 CLK] [2 CLK] [3 CLK]
tWTR [ Auto]
Allows you to specify the write to read delay when accessing the same
DRAM. Conguration options: [1 CLK] [2 CLK] [3 CLK] [Auto]
tWRWR [ Auto]
Allows you to specify the Twrwr time. Conguration options: [Auto] [1 CLK] [2
CLK] [3 CLK]
tRDRD [ Auto]
Allows you to specify the Trdrd time. Conguration options: [Auto] [2 CLK] [3
CLK] [4 CLK] [5 CLK]
tRFC0/1/2/3 [ Auto]
Allows you to specify the Trfc0/1/2/3 time. Conguration options: [Auto] [75ns]
[105ns] [127.5ns] [195ns] [327.5ns]
Memory Over Voltage [Auto]
Allows you to select the Memory Over Voltage. The increment is 6.25mV.
Conguration options: [Auto] [6.25mV] [12.5mV] [18.75mV] [25mV] ~ [393.75mV]
Chipset Voltage:
Chipset Voltage [Auto]
Allows you to set the Chipset Voltage.
Conguration options: [Auto] [+ 50mv] [+ 100mv] [+ 150mv]
