Playback of HD DVD and Blu-Ray discs
• For better playback quality, we recommend that you follow the system requirements
listed below.
Suggested list
CPU AMD
®
Phenom™ II x3 720
DIMM DDR3 1333 (1GB or higher)
BIOS setup Frame Buffer Size--256MB or higher
File format
Best resolution
Windows
®
XP Windows
®
Vista
Non-protected clips 1920 x 1080p 1920 x 1080p
HD-DVD 1920 x 1080p 1280 x 1080p
Blu-Ray 1280 x 1080p 1280 x 1080p
• To play HD DVD or Blu-Ray disc, ensure to use HDCP compliant devices and software.
17. USB 2.0 ports 5 and 6. These two 4-pin Universal Serial Bus (USB) ports are for
USB 2.0 devices.
1.10.2 Internal connectors
1. IEEE 1394a connector (10-1 pin IE1394_1)
This connector is for an IEEE 1394a port. Connect the IEEE 1394a module cable to this
connector, then install the module to a slot opening at the back of the system chassis.
Never connect a USB cable to the IEEE 1394a connector. Doing so will damage the
motherboard!
ASUS M4A785TD-V EVO 1-21
