Asus Maximus IX Code User Manual

x
(continued on the next page)
LAN
Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated
Media Access Controller (MAC) and physical layer (PHY)
Anti-surge LANGuard (On-Board)
ROG GameFirst IV
Wireless & Bluetooth
Wi-Fi with MU-MIMO 802.11 a/b/g/n/ac supports dual frequency band
2.4/5 GHz
Up to 867Mbps transfer speed
Bluetooth v4.1*
* Support for the Bluetooth specification depends on the Windows
®
version. Windows
®
7/8.1 can support up to Bluetooth 4.0.
Audio
ROG SupremeFX S1220 8-Channel High Definition Audio CODEC
- Supports up to 32-Bit/192kHz playback*
- Impedance sense front and rear panel headphone outputs
- High quality 120dB SNR stereo playback output and 113dB SNR
recording input
- ES9023P High Denition DAC
- SupremeFX Shielding Technology
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- Optical S/PDIF out port at back panel
Audio Features:
- Sonic Studio III
- Sonic Radar III
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-Channel audio
USB
Intel
®
Z270 Chipset - supports ASUS USB 3.1 Boost:
- 6 x USB 3.0 ports ( 4 ports at back panel [blue], 2 ports at mid-
board [grey])
- 6 x USB 2.0 ports ( 4 ports at back panel [black], 2 ports at mid-
board [black])*
ASMedia
®
USB 3.1 controller - supports ASUS USB 3.1 Boost:
- 1 x USB 3.1 front panel connector
- 2 x USB 3.1 ports (1 Type-A [red] and 1 Type-C [black] at back
panel)
* 2 x USB 2.0 ports at mid-board share with ROG extension (ROG_EXT)
port.
Back I/O Ports
1 x Clear CMOS Button
1 x BIOS Flashback Button
1 x Wi-Fi Module
1 x HDMI 1.4b
1 x DisplayPort 1.2
4 x USB 2.0 ports [black]
4 x USB 3.0 ports [blue]
1 x Anti-surge LAN (RJ45) port
2 x USB 3.1 ports (1 x Type-A [red] and 1 x Type-C [black])
1 x Optical S/PDIF out
5 x Gold-plated audio jacks
MAXIMUS IX FORMULA specifications summary
