ASUS MAXIMUS IX CODE
2-9
Chapter 2
2.1.7 Front I/O connector
To install ASUS Q-Connector
USB 2.0
AAFP
To install USB 2.0 connector
To install front panel audio connector To install system speaker connector
USB 3.0
To install USB 3.0 connector
USB 3.1
To install USB 3.1 connector
Thisconnectorwillonlytinone
orientation. Push the connector until it
clicks into place.
