Chapter 2: Basic Installation
Chapter 2
2.3 Motherboard rear and audio connections
2.3.1 Rear I/O connection
* and ** : Refer to the tables on the next page for LAN port LEDs, and audio port definitions.
Rear panel connectors
1.
ClearCMOSbutton(CLR_CMOS).PressthisbuttontocleartheBIOSsetup
information only when the systems hangs due to overclocking.
2. DisplayPort
3. Intel
®
USB2.0ports7,8,9,and10
4. Intel
®
USB3.0ports3,4,5,and6
5. LAN(RJ-45)port*
6. USBBIOSFlashbackbutton
7. Wi-Fi802.11a/b/g/n/ac,BluetoothV4.1
8. HDMI port
9. USB3.1Type-AportEA3
10. USB3.1Type-CportEC2
11. OpticalS/PDIFOUTport
12. AudioI/Oports**
