6
MAKING THE CONNECTIONS
Connecting the Signal Cable: Plug one end of the VGA Cableto the LCD monitor’s VGA
port, the other end to the computer's VGA socket and tighten the two screws on the cable
connector. Moreover, for MM17T, you can buy an extra 24-Pin DVI-D cable from your dealer
for the digital signal connection if preferred.
Connecting the Power Cord: Plug one end of the AC-power cord to the LCD monitor’s AC
input socket, the other end to the power outlet.
Connecting the Audio Cable (MM17T only): Plug the audio cable between the computer
multi-media (or audio) card's audio output and monitor's audio jack.
Caution: If the AC outlet is not grounded (with three holes), install the proper grounding
adapter (not supplied).
Figure 2
1.
To Next Page
