Asus N56VM User Manual

Notebook PC User Manual A-15
Software Problem - BIOS
Updating the BIOS.
1. Please verify the Notebook PC’s exact model and download the
latest BIOS file for your model from the ASUS website and save
it in your flash disk drive.
2. Connect your flash disk drive to the Notebook PC and power on
the Notebook PC.
3. Use the Start Easy Flash function on the Advanced page of the
BIOS Setup Utility. Follow the instructions shown.
4. Locate the latest BIOS file and start updating (flashing) the BIOS.
ASU S Te k. E as y Fl ash Ut il it y
[ ]: Sw it ch [ ] : C ho ose [q ] : Ex it
FLA SH T YP E: G en er ic F la sh T ype
C ur rent P la tfor m
Pla tf or m: N 56
Ver si on : 20 0
Bui ld D ate: D ec 6 2 01 1
N ew P la tf orm
Pla tf or m: U nk ow n
Ver si on : Un ko wn
Bui ld D ate: U nk own
5. You must Restore Defaults on the Exit page after updating
(flashing) the BIOS.
: Se le ct S cr ee n
: Se le ct Ite m
Ent er : Sele ct
+/— : Ch an ge Opt .
F1: Gene ra l He lp
F9: Opti mi ze d De fa ul ts
F10 : Sa ve ES C: Ex it
Ver si on 2.0 1. 12 08 . Co py ri ght (C ) 20 11 A me ri ca n Me ga tr en ds, In c.
A pt io Set up U ti lity - C op yrig ht ( C) 201 1 Am er ican M eg atre nd s, I nc.
M ainMai n Adv an ce d C hi ps et Bo ot Se cu ri ty Sa ve & E xi t
PO ST Log o Ty pe [S ta ti c]
St ar t Ea sy F la sh
Pl ay POS T So un d [No ]
Sp ea ker Vo lu me [4]
In te rnal P oi nt ing De vi ce [En ab le d]
Wa ke On Li d Op en [En ab le d]
AS US USB C ha rg er+ in b atte ry m od e [Di sa bl ed ]
In te l Vi rt ua li zati on T echn ol og y [Di sa bl ed]
VT -d [En ab le d]
SA TA C onfi gu ra ti on
In te l( R) A nt i- Th eft Te ch no logy C on fi gura ti on
US B Co nfig ur at io n
In te l( R) S ma rt C onne ct T ec hnol og y
Ne tw or k St ac k
Pre ss E NTER t o ru n th e ut ilit y
to se le ct a nd u pd ate BI OS .
FS0
FS1

Asus N56VM Specifications

General

Bus type	DMI
Tjunction	105 C °C
Processor cache	6 MB
Processor cores	4
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-3600 Mobile series
Processor socket	Socket G2
Processor threads	8
Processor codename	Ivy Bridge
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.3 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	23
Maximum number of PCI Express lanes	16
On-board graphics card	Yes
On-board graphics card ID	0x166
Discrete graphics card model	NVIDIA® GeForce® GT 630M
On-board graphics card model	Intel® HD Graphics 4000
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR3
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Form factor	Clamshell
Product type	Laptop
Product color	Black, Stainless steel
Motherboard chipset	Intel HM76 Express
Memory slots	2x SO-DIMM
Internal memory	6 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Maximum internal memory	16 GB
HDD size	2.5 \
Storage media	HDD
Optical drive type	Blu-Ray DVD Combo
Total storage capacity	750 GB
Compatible memory cards	SD, Memory Stick (MS), MMC, MS PRO
Display diagonal	15.6 \
Native aspect ratio	16:9
Speakers manufacturer	Bang & Olufsen
Wi-Fi standards	802.11g, 802.11b, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Ethernet LAN data rates	10, 1000, 100 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Home Premium
Battery capacity	5200 mAh
Battery technology	-
Number of battery cells	6
AC adapter power	120 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	6.3 A
AC adapter output voltage	19 V
Cable lock slot type	Kensington
Password protection type	HDD, User, BIOS
Processor ARK ID	64899
Processor package size	37.5 x 37.5 (rPGA988B) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	255 mm
Width	380 mm
Weight	2700 g
Height (rear)	34 mm
Height (front)	27.3 mm
