Notebook PC E-Manual
F. (Optional) If an HDD is currently attached to the HDD bay, refer to
the following steps on how to remove the old HDD:
1. Remove all the screws on the sides of the HDD bay.
2. Remove the old HDD from the HDD bay then place it on a
at dry surface with its PCB (Printed Circuit Board) facing up,
as shown in the illustration below.
old HDD
HDD bay
To Next Page
