ASUS P3V4X User’s Manual62
4. BIOS SETUP
4. BIOS SETUP
I/O Device Config
Onboard Parallel Port [378H/IRQ7]
This field sets the address of the onboard parallel port connector. If you
disable this feature, Parallel Port Mode and ECP DMA Select configu-
rations will not be available. Configuration options: [Disabled] [378H/
IRQ7] [278H/IRQ5]
Parallel Port Mode [ECP+EPP]
This field allows you to set the operation mode of the parallel port. [Nor-
mal] allows normal-speed operation but in one direction only; [EPP] al-
lows bidirectional parallel port operation; [ECP] allows the parallel port
to operate in bidirectional DMA mode; [ECP+EPP] allows normal speed
operation in a two-way mode. Configuration options: [Normal] [EPP]
[ECP] [ECP+EPP]
ECP DMA Select [3]
This field allows you to configure the parallel port DMA channel for the
selected ECP mode. This selection is available only if you select [ECP] or
[ECP+EPP] in Parallel Port Mode above. Configuration options: [1] [3]
[Disabled]
