ASUS P4P800 Deluxe motherboard user guide
5-27
5.4.2 Entering VIA
®
Tech RAID BIOS Utility
1. Boot-up your computer.
2. During POST, press <Tab> to enter VIA RAID configuration utility.
The following menu options will appear.
4. Connect the power cable to the power connector on each drive.
5. Proceed to section 5.4.2 for the next procedure.
Channel Drive Name Array Name Mode Size(GB) Status
Channel0 Master XXXXXXXXXX xxxxx xxx.xx Hdd
Channel0 Slave XXXXXXXXXX xxxxx xxx.xx Hdd
Channel1 Master No Drive
Channel1 Slave No Drive
VIA Tech. RAID BIOS Ver 1.00
Create Array
Delete Array
Create/Delete Spare
Select Boot Array
Serial Number View
Create a RAID array with
the hard disk attached to
VIA IDE controller
F1 : View Array/Disk Status
, : Move to next item
Enter: Confirme the selection
ESC : Exit
On the upper-right side of the screen is the message and legend box. The
keys on the legend box allows you to navigate through the setup menu
options. The message describes the function of each menu item. The
following lists the keys found in the legend box with their corresponding
functions.
F1 : View Array/Disk Status
↑, ↓ : Move to the next item
Enter : Confirm the selection
ESC : Exit
The RAID BIOS information on the setup screen shown is for reference
only. What you see on your screen may not be exactly the same as
shown.
To Next Page
