5-305-30
5-305-30
5-30
Chapter 5: Software supportChapter 5: Software support
Chapter 5: Software supportChapter 5: Software support
Chapter 5: Software support
A copy progress appears if you previously selected offline copy.
f. After copying the data to the target drives, a confirmation box
appears. Press <Y> to create the RAID set, or <N> to return to the
utility main menu.
• For details on the Silicon Image SATARaid™ RAID configuration, refer
to the “Sil3114 User’s Manual” in the motherboard support CD.
• A RAID 5 configuration requires at least 1 GB of system memory and
3 GHz processor core speed for optimum performance.
• You can only set the SATALink™ RAID 5 configuration using the
SATALink™ SATA RAID Management Software.
• Make sure to install the Silicon Image SATA Link Sil 3114 driver and
the Silicon Image RAID 5 Array Management Utility before using
RAID 5 configuration. These are available from the support CD.
Silicon Image Array Management SoftwareSilicon Image Array Management Software
Silicon Image Array Management SoftwareSilicon Image Array Management Software
Silicon Image Array Management Software
The Silicon Image Array Management Software is a Windows
®
-based
application that allows you to create a RAID set(s) in Windows
®
XP
environment. This application is available from the support CD that came
with the motherboard package.
To launch the application from Windows
®
XP, click
StartStart
StartStart
Start, select
AllAll
AllAll
All
Programs Programs
Programs Programs
Programs >
Silicon Image Silicon Image
Silicon Image Silicon Image
Silicon Image >
Sam.Sam.
Sam.Sam.
Sam.
